10174

Name: Festo 10174 End plate kit NEV-1DA/DB-ISO
Brand: Festo

End plate kit NEV-1DA/DB-ISO

This Festo industrial component with part number 10174 is built on a die-cast aluminum sub-base weighing 280 g and features G3/8 pneumatic connections for ports 1, 3, and 5. The unit conforms to ISO 5599-1 standards, matches VDMA 24345-D-1 designation, and complies with VDMA24364-B1/B2-L LABS (PWIS) requirements. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 10174
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 10174.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Designation to VDMA: VDMA 24345-D-1
Conforms to standard: ISO 5599-1
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Product weight: 280 g
Pneumatic connection 1: G3/8
Pneumatic connection 3: G3/8
Pneumatic connection 5: G3/8
Material of sub-base: Die-cast aluminum
Official Festo technical specifications: Designation to VDMA VDMA 24345-D-1 Conforms to standard ISO 5599-1 LABS (PWIS) conformity VDMA24364-B1/B2-L Product weight 280 g Pneumatic connection 1 G3/8 Pneumatic connection 3 G3/8 Pneumatic connection 5 G3/8 Material of sub-base Die-cast aluminum 6/5/26 –

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 10174. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
