11948

Name: Festo 11948 Barb fitting CN-1/4-PK-6
Brand: Festo

Barb fitting CN-1/4-PK-6

The Festo part number 11948 is an industrial component featuring an aluminum housing with a nominal width of 5.3 mm, an external thread G1/4 pneumatic connection 1, and a pneumatic connection 2 for 8 mm outside diameter tubing. This unit operates within a pressure range of -0.95 bar to 10 bar and an ambient temperature range of 0 °C to 60 °C using compressed air conforming to ISO 8573-1:2010 [7:-:-]. It incorporates a sealing ring on the screwed plug, offers a moderate corrosion resistance class (CRC) of 2, and requires oil lubrication for further use while maintaining RoHS and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a formal quote for this component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 11948
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 11948.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Nominal width: 5.3 mm
Type of seal on screwed plug: Sealing ring
Operating pressure for entire temperature range: -0.95 bar...10 bar
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Ambient temperature: 0 °C...60 °C
Pneumatic connection 1: External thread G1/4
Pneumatic connection 2: for pneumatic tubing outside diameter 8 mm
Note on materials: RoHS compliant
Housing material: Aluminum
Official Festo technical specifications: Nominal width 5.3 mm Type of seal on screwed plug Sealing ring Operating pressure for entire temperature range -0.95 bar...10 bar Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Information on operating and pilot media Operation with oil lubrication possible (required for further use) Corrosion resistance class (CRC) 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Ambient temperature 0 °C...60 °C Pneumatic connection 1 External thread G1/4 Pneumatic connection 2 for pneumatic tubing outside diameter 8 mm Note on materials RoHS compliant Housing material Aluminum 6/5/26 –

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 11948. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
