Name: Festo 119674 Throttle plate GRO-ZP-3-ISO
Brand: Festo

Throttle plate GRO-ZP-3-ISO

Festo Throttle plate GRO-ZP-3-ISO, part number 119674, is documented in the official Festo United States product data sheet. Review the technical specifications and operating conditions below when requesting a quotation.

Request pricing and availabilityCommercial response for your destination and required quantity.

Request a Quote

Manufacturer: Festo
Part number: 119674
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 119674.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationTechnical documents are stored and served from our system.

Verified configuration

Technical Specifications

Identification and family-level technical context are preserved from reviewed source evidence and official English-language manufacturer documentation.

Valve function: Flow control function
Operating pressure: 0 bar...16 bar
Normal nominal ow rate (normalized to DIN 1343): 1500 l/min
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 0 - No corrosion stress
LABS (PWIS) conformity: VDMA24364-B2-L
Temperature of medium: -20 °C...80 °C
Ambient temperature: -20 °C...80 °C
Type of mounting: With through-hole
Official Festo technical specifications: Valve function Flow control function Operating pressure 0 bar...16 bar Normal nominal ow rate (normalized to DIN 1343) 1500 l/min Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Information on operating and pilot media Operation with oil lubrication possible (required for further use) Corrosion resistance class (CRC) 0 - No corrosion stress LABS (PWIS) conformity VDMA24364-B2-L Temperature of medium -20 °C...80 °C Ambient temperature -20 °C...80 °C Type of mounting With through-hole 6/5/26 –

Technical library

Documents and Data Sheets

PDF · View document →

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 119674. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
