Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
13289
Clamping module EV-15/40-4
The Festo part number 13289 is a single-acting industrial component featuring a 4 mm stroke and a 15x40 clamping area. Constructed with a die-cast aluminum housing and a TPE-U(PU) diaphragm, this 45 g unit operates with compressed air according to ISO 8573-1:2010 [7:-:-] at pressures ranging from 0.2 MPa to 0.6 MPa (2 bar to 6 bar, 29 psi to 87 psi). It includes VDMA24364-B1/B2-L LABS conformity, through-hole mounting, an M5 pneumatic connection, and an ambient temperature range of -20 °C to 40 °C, while excluding metals with more than 5% copper by mass for Li-ion battery production suitability. Submit the exact part number, quantity, and application requirements to receive a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 13289
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 13289.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Stroke
- 4 mm
- Clamping area
- 15x40
- Mounting position
- Any
- Mode of operation
- Single-acting
- Operating pressure
- 0.2 MPa...0.6 MPa | 2 bar...6 bar | 29 psi...87 psi
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Suitability for the production of Li-ion batteries
- Metals with more than 5% by mass of copper are excluded from use. | This excludes printed circuit boards, cables, electrical connectors and | coils.
- Ambient temperature
- -20 °C...40 °C
- Product weight
- 45 g
- Type of mounting
- With through-hole
- Pneumatic connection
- M5
- Housing material
- Die-cast aluminum
- Diaphragm material
- TPE-U(PU)
- Official Festo technical specifications
- Stroke 4 mm Clamping area 15x40 Mounting position Any Mode of operation Single-acting Operating pressure 0.2 MPa...0.6 MPa 2 bar...6 bar 29 psi...87 psi Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] LABS (PWIS) conformity VDMA24364-B1/B2-L Suitability for the production of Li-ion batteries Metals with more than 5% by mass of copper are excluded from use. This excludes printed circuit boards, cables, electrical connectors and coils. Ambient temperature -20 °C...40 °C Product weight 45 g Type of mounting With through-hole Pneumatic connection M5 Housing material Die-cast aluminum Diaphragm material TPE-U(PU) 6/5/26 –
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 13289. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
