Reference imageConfirm configuration by manufacturer part number.
Festo
133069
Push-in L-fitting NPQP-LQ-R38-Q12-FD-P10
The Festo part number 133069 is a standard-sized, L-shaped industrial component featuring a 6.9 mm nominal width, an external thread R3/8 pneumatic connection 1, and a pneumatic connection 2 for a 12 mm outside diameter tubing. Built with a polypropylene housing and an external hexagon SW22 mounting type, this pack of 10 components utilizes the push-pull principle with an additional lengthwise push-in connector and a transparent white releasing ring. It operates on compressed air according to ISO 8573-1:2010 [7:-:-] within a temperature range of -20 °C to 60 °C, supporting an operating pressure from -0.095 MPa to 0.45 MPa across the entire temperature range and up to 1 MPa depending on the temperature. The unit weighs 26 g, features a CRC 4 rating for particularly high corrosion stress, and conforms to VDMA24364 Zone III LABS while remaining RoHS compliant. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 133069
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 133069.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- Standard
- Nominal width
- 6.9 mm
- Design
- L-shape, additional push-in connector, lengthwise
- Pack size
- 10
- Structural design
- Push-pull principle
- Operating pressure for entire temperature range
- -0.095 MPa...0.45 MPa | -0.95 bar...4.5 bar | -13.775 psi...65.25 psi
- Temperature-dependent operating pressure
- -0.095 MPa...1 MPa | -0.95 bar...10 bar | -13.775 psi...145 psi
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Lubricated operation possible
- Corrosion resistance class (CRC)
- 4 - Particularly high corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- For use in the food industry
- See supplementary material information
- Ambient temperature
- -20 °C...60 °C
- Product weight
- 26 g
- Type of mounting
- External hexagon SW22
- Pneumatic connection 1
- External thread R3/8
- Pneumatic connection 2
- for pneumatic tubing outside diameter 12 mm
- Releasing ring color
- transparent white
- Note on materials
- RoHS compliant
- Housing material
- PP
- Material of tube retaining claw
- high-alloy stainless steel
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 133069. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
