Name: Festo 1396090 Vacuum suction cup VAS-30-1/8-PUR-B
Brand: Festo

Vacuum suction cup VAS-30-1/8-PUR-B

The Festo part number 1396090 is a round, flat industrial component featuring a 30 mm suction cup diameter, a 24.8 mm effective diameter, and a nominal width of 3 mm with an upward connection position. This blue component provides 34 N of holding force at its nominal operating pressure of -0.07 MPa, incorporates a 1.9 mm height compensation, and weighs 12 g with a 60 +/-5 Shore hardness. It operates within a temperature range of -20 °C to 60 °C and an operating pressure range of -0.095 MPa to 0 MPa using atmospheric air based on ISO 8573-1:2010 [7:-:-]. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 1396090
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 1396090.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Suction cup height compensation: 1.9 mm
Nominal width: 3 mm
Suction cup diameter: 30 mm
Suction cup volume: 1.29 cm³
Eﬀective suction cup diameter: 24.8 mm
Connection position: up
Mounting position: Any
Suction cup shape: Round, at
Operating pressure: -0.095 MPa...0 MPa | -0.95 bar...0 bar | -13.775 psi...0 psi
Nominal operating pressure: -0.07 MPa | -0.7 bar | -10.15 psi
Operating medium: Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-A1-L
Ambient temperature: -20 °C...60 °C
Holding force at nominal operating pressure: 34 N
Product weight: 12 g
Type of mounting: Via vacuum connection
Vacuum connection: G1/8
Color: Blue
Shore hardness: 60 +/-5
Material of screwed plug: Brass
Note on materials: RoHS compliant
Suction cup material: PUR

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 1396090. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
