Festo
13968
Barb fitting CRCN-M5-PK-4
The Festo part number 13968 is an industrial component featuring an M5 external thread pneumatic connection 1 and a pneumatic connection 2 for 6 mm outside diameter tubing, with a nominal width of 2.5 mm and a product weight of 2.58 g. Constructed with a high-alloy stainless steel housing and an NBR and high-alloy stainless steel threaded seal, it operates at pressures from -0.95 bar to 10 bar across ambient temperatures of 0 °C to 60 °C using compressed air per ISO 8573-1:2010 [7:-:-]. This RoHS-compliant component provides a corrosion resistance class of 2 for moderate corrosion stress, VDMA24364-B2-L LABS conformity, a sealing ring on the screwed plug, and is packaged in a pack size of 10 with oil lubrication operation possible. Please submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 13968
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 13968.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 2.5 mm
- Type of seal on screwed plug
- Sealing ring
- Pack size
- 10
- Operating pressure for entire temperature range
- -0.95 bar...10 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B2-L
- For use in the food industry
- See supplementary material information
- Ambient temperature
- 0 °C...60 °C
- Product weight
- 2.58 g
- Pneumatic connection 1
- External thread M5
- Pneumatic connection 2
- for pneumatic tubing outside diameter 6 mm
- Note on materials
- RoHS compliant
- Housing material
- high-alloy stainless steel
- Material of threaded seal
- NBR | high-alloy stainless steel
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 13968. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
