Reference imageConfirm configuration by manufacturer part number.
Festo
14015
Vacuum generator VAD-1/8
The Festo 14015 is a T-shaped industrial component featuring a 0.8 mm nominal width Laval nozzle and a die-cast aluminum housing configured with G1/8 pneumatic connections 1 and 3 alongside a G1/8 vacuum connection. Designed for high vacuum ejector characteristics, it supports an operating pressure range of 0.15 MPa to 1 MPa (1.5 bar to 10 bar or 21.75 psi to 145 psi) and delivers a maximum vacuum of 80 percent using compressed air compliant with ISO 8573-1:2010 [7:4:4]. This unit accommodates any mounting position via a through-hole and operates within a medium and ambient temperature range of -20 °C to 80 °C with VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 14015
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 14015.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width of Laval nozzle
- 0.8 mm
- Mounting position
- Any
- Ejector characteristics
- High vacuum
- Structural design
- T-shape
- Operating pressure
- 0.15 MPa...1 MPa | 1.5 bar...10 bar | 21.75 psi...145 psi
- Max. vacuum
- 80 %
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Temperature of medium
- -20 °C...80 °C
- Ambient temperature
- -20 °C...80 °C
- Type of mounting
- With through-hole
- Pneumatic connection 1
- G1/8
- Pneumatic connection 3
- G1/8
- Vacuum connection
- G1/8
- Housing material
- Die-cast aluminum
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 14015. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
