Reference imageConfirm configuration by manufacturer part number.
Festo
150239
Timer PZVT-300-SEC
The Festo part number 150239 is an industrial mechanical sequence counter featuring a pneumatic actuator designed for front panel mounting via M5 internal threads. It operates within a 2 bar to 6 bar pressure range, providing an adjustable delay time of 20 s to 300 s with a setting accuracy of ± 6 s, a repetition accuracy of ± 3 s, and a pause period for reset of 200 ms. Built with an ABS housing yielding an IP54 degree of protection when utilizing a protective cap and panel frame, this component functions with compressed air conforming to ISO 8573-1:2010 [7:4:4] and maintains ATEX certification for Zones 1, 2, 21, and 22. To receive pricing for this component, submit your exact part number, quantity, and application requirements for an RFQ.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 150239
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 150239.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Structural design
- Mechanical sequence counter with pneumatic actuator
- Switch-off pressure
- 0.1 bar
- Operating pressure
- 2 bar...6 bar
- Switch-on pressure
- 1.6 bar
- Normal nominal ow rate (normalized to DIN 1343)
- 50 l/min
- Adjustable delay time
- 20 s...300 s
- Setting accuracy
- ± 6 s
- Pause period for reset
- 200 ms
- Repetition accuracy of time setting
- ± 3 s
- Explosion prevention and protection
- Zone 1 (ATEX) | Zone 2 (ATEX) | Zone 21 (ATEX) | Zone 22 (ATEX)
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Operation with oil lubrication not possible
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Degree of protection
- IP54 | With protective cap and panel frame | As per IEC 60529
- Ambient temperature
- -10 °C...60 °C
- Product weight
- 45 g
- Type of mounting
- Front panel mounting
- Pneumatic connection
- Internal thread M5
- Note on materials
- RoHS compliant
- Housing material
- ABS
