Festo
151211
Length compensator VAL-1/4-20
The Festo part number 151211 is an industrial component featuring a suction cup holder with a 20 mm height compensator and a structural design providing a vacuum connection at the top. Constructed with an aluminum housing, NBR seals, and a retainer bracket of aluminum, POM, and galvanized steel, this unit supports any mounting position via an M26x1.5 external thread alongside G1/4 suction cup and vacuum connections. It operates within a pressure range of -0.95 bar to 8 bar and an ambient temperature range of -10 °C to 60 °C using compressed air meeting ISO 8573-1:2010 [7:-:-]. Featuring RoHS compliance, a CRC rating of 2, LABS conformity to VDMA24364-B1/B2-L, and a weight of 118 g, it meets specific moderate corrosion stress requirements. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 151211
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 151211.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Suction cup holder height compensator
- 20 mm
- Mounting position
- Any
- Structural design
- Vacuum connection at top
- Operating pressure
- -0.95 bar...8 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 °C...60 °C
- Product weight
- 118 g
- Type of mounting
- With external thread M26x1.5
- Suction cup mounting
- G 1/4
- Vacuum connection
- G1/4
- Note on materials
- RoHS-compliant
- Seals material
- NBR
- Housing material
- Aluminum
- Retainer bracket material
- Aluminum | POM | Steel, galvanized
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 151211. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
