151718

Name: Festo 151718 Illuminating seal MEB-LD-230AC
Brand: Festo

Illuminating seal MEB-LD-230AC

This Festo industrial component, part number 151718, is a transparent TPE-U(PU) housing featuring an LED switching position indication and a protective earth connection. Designed for mounting on an air solenoid valve with an M2.5 central screw, it includes a Type C rectangular electrical connection as per DIN EN 175301-803 for MSEB, operating at a nominal AC voltage of 230 V with 0.33 W nominal power luminous seal and 2.5 kV surge resistance. The unit weighs 0.6 g, maintains an IP65 degree of protection across an ambient temperature range of -25 °C to 85 °C, accommodates permissible voltage fluctuations of +/- 10%, meets contamination level 3, and holds CE and UKCA markings as per respective low voltage and electrical equipment directives alongside VDMA24364-B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to receive a formal quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 151718
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 151718.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Switching position indication: LED
Type of mounting: On air solenoid valve with M2.5 central screw
Product weight: 0.6 g
Electrical connection: Type C | As per DIN EN 175301-803 | Rectangular design MSEB
Nominal operating voltage AC: 230 V
Surge resistance: 2.5 kV
Protective earth connection: Available
Nominal power luminous seal: 0.33 W
Permissible voltage uctuations: +/- 10%
Degree of protection: IP65
Ambient temperature: -25 °C...85 °C
CE marking (see declaration of conformity): As per EU low voltage directive
UKCA marking (see declaration of conformity): To UK instructions for electrical equipment
LABS (PWIS) conformity: VDMA24364-B2-L
Contamination level: 3
Housing material: TPE-U(PU)
Color: Transparent

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 151718. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
