Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
152511
Multi-socket KDVF6-22
The Festo 152511 is an industrial component featuring a 6 mm nominal width and a PK-6 pneumatic connection supporting up to 22 maximum connections in a gray finish. Designed for compressed air operating media according to ISO 8573-1:2010 [7:-:-], this part operates within a pressure range of -0.95 bar to 10 bar and a temperature span of -10 °C to 60 °C for both the medium and ambient environment. It offers a corrosion resistance class of CRC 2 for moderate corrosion stress, VDMA24364-B1/B2-L LABS conformity, RoHS compliant materials, and permits operation with oil lubrication which is required for further use. Submit the exact part number, quantity, and application requirements to receive a quote for this component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 152511
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 152511.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 6 mm
- Operating pressure
- -0.95 bar...10 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Temperature of medium
- -10 °C...60 °C
- Ambient temperature
- -10 °C...60 °C
- Max. connections
- 22
- Pneumatic connection
- PK-6
- Color
- Gray
- Note on materials
- RoHS compliant
- Official Festo technical specifications
- Nominal width 6 mm Operating pressure -0.95 bar...10 bar Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Information on operating and pilot media Operation with oil lubrication possible (required for further use) Corrosion resistance class (CRC) 2 - Moderate corrosion stress LABS (PWIS) conformity VDMA24364-B1/B2-L Temperature of medium -10 °C...60 °C Ambient temperature -10 °C...60 °C Max. connections 22 Pneumatic connection PK-6 Color Gray Note on materials RoHS compliant 6/5/26 –
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 152511. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
