Festo
153444
Non return valve HA-M5-QS-4
The Festo 153444 is a nickel-plated brass non-return industrial component featuring an M5 pneumatic connection on port 1 and a QS-4 connection on port 2 with a screw-in mounting type. It delivers a normal nominal flow rate of 148 l/min under an operating pressure range of -1 bar to 10 bar using compressed air as per ISO 8573-1:2010 [7:-:-]. Designed with a minimum opening differential pressure of 0.1 bar and a closing differential pressure of 0.2 bar, this RoHS-compliant part weighs 7.2 g and supports oil-lubricated operation. Submit the exact part number, quantity, and application requirements to request a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 153444
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 153444.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- Non-return function
- Pneumatic connection 1
- M5
- Pneumatic connection 2
- QS-4
- Type of mounting
- Screw-in
- Normal nominal ow rate (normalized to DIN 1343)
- 148 l/min
- Operating pressure
- -1 bar...10 bar
- Ambient temperature
- 0 °C...60 °C
- Housing material
- Brass, nickel-plated
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Min. differential pressure, opening
- 0.1 bar
- Min. differential pressure, closing
- 0.2 bar
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Product weight
- 7.2 g
- Note on materials
- RoHS compliant
