Reference imageConfirm configuration by manufacturer part number.
Festo
153831
Push-in cap QSC-5/16-U
The Festo 153831 is a standard blanking plug featuring a 4.9 mm nominal width and a 18.1 mm tubing insertion depth for 5/16" pneumatic tubing outside diameter. Built with a PBT housing and a gray releasing ring, it utilizes the push-pull principle and operates at pressures from -0.095 MPa to 1 MPa across an ambient temperature range of -10 °C to 60 °C (14 °F to 140 °F). This RoHS-compliant component supports compressed air media as per ISO 8573-1:2010 [7:-:-] with lubricated operation possible, weighs 4.7 g, and features a corrosion resistance class of 1 with any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 153831
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 153831.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- Standard
- Nominal width
- 4.9 mm
- Tubing insertion depth
- 18.1 mm
- Mounting position
- Any
- Design
- Blanking plug
- Pack size
- 1
- Structural design
- Push-pull principle
- Operating pressure for entire temperature range
- -0.095 MPa...1 MPa | -0.95 bar...10 bar | -13.775 psi...145 psi
- Maritime classication
- See certicate
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Lubricated operation possible
- Corrosion resistance class (CRC)
- 1 - Low corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 °C...60 °C
- Product weight
- 4.7 g
- Pneumatic connection 1
- For pneumatic tubing outside diameter 5/16"
- Ambient temperature Fahrenheit
- 14 °F...140 °F
- Releasing ring color
- Gray
- Note on materials
- RoHS compliant
- Housing material
- PBT
- Releasing ring material
- POM
- Material of tubing seal
- NBR
- Material of tube retaining claw
- high-alloy stainless steel
