Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas+1 417 261 6001 info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
1587988
Hand slide valve VBOH-32-G12
Festo Hand slide valve VBOH-32-G12, part number 1587988, is documented in the official Festo United States product data sheet. Review the technical specifications and operating conditions below when requesting a quotation.
Request pricing and availabilityCommercial response for your destination and required quantity.
Request a Quote- Manufacturer
- Festo
- Part number
- 1587988
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 1587988.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationTechnical documents are stored and served from our system.
Verified configuration
Technical Specifications
Identification and family-level technical context are preserved from reviewed source evidence and official English-language manufacturer documentation.
- Valve function
- 3/2-way, bistable
- Pneumatic connection 1
- G1/2
- Pneumatic connection 2
- G1/2
- Actuation type
- Manual
- Type of mounting
- In-line installation | Screw-in
- Normal nominal ow rate (normalized to DIN 1343)
- 3420 l/min
- Nominal width
- 12.1 mm
- Operating pressure
- -0.095 MPa...1.2 MPa | -0.95 bar...12 bar
- Ambient temperature
- -10 °C...80 °C
- Housing material
- Wrought aluminum alloy, anodized
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Width dimension
- 45 mm
- Application note
- Please only screw in ttings with a cylindrical thread. Installing tapered | threads can damage the housing and cause the sleeve to jam or | malfunction.
- Sealing principle
- Soft
- Mounting position
- Any
- Structural design
- Sleeve valve
- Type of control
- directly
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Temperature of medium
- -10 °C...80 °C
- Actuating force
- 37 N
- Product weight
- 90 g
- Material of screwed plug
- Wrought aluminum alloy, anodized
- Note on materials
- RoHS compliant
- Seals material
- NBR
Technical library
Documents and Data Sheets
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 1587988. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
