Name: Festo 162788 Branching module FRM-H-1/8-D-MINI
Brand: Festo

Branching module FRM-H-1/8-D-MINI

The Festo 162788 is a die-cast aluminum branching module featuring any mounting position, G1/8 pneumatic connections 1 and 2, and G1/4 pneumatic connections 3 and 4. This RoHS-compliant industrial component operates between 0.015 MPa and 1.6 MPa using compressed air or inert gases, delivering a standard nominal flow rate of 1100 l/min in the main flow direction from 1 to 2. It withstands temperatures and storage conditions from -10 °C to 60 °C while offering a moderate corrosion resistance class of 2 and VDMA24364-B1/B2-L LABS conformity at a product weight of 325 g. Submit the exact part number, quantity, and application requirements to request a formal quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 162788
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 162788.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Mounting position: Any
Structural design: Branching module
Operating pressure: 0.015 MPa...1.6 MPa | 0.15 bar...16 bar
Standard nominal ow rate in main ow direction 1 -> 2: 1100 l/min
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-] | Inert gases
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Storage temperature: -10 °C...60 °C
Air quality class at the output: Compressed air as per ISO 8573-1:2010 [7:-:-] | Inert gases
Temperature of medium: -10 °C...60 °C
Ambient temperature: -10 °C...60 °C
Product weight: 325 g
Pneumatic connection 1: G1/8
Pneumatic connection 2: G1/8
Pneumatic connection 3: G1/4
Pneumatic connection 4: G1/4
Note on materials: RoHS compliant
Housing material: Die-cast aluminum

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 162788. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
