Name: Festo 1709137 Electric pressure regulator PREL-90-HP3-V1-A-40CFX-S1-5
Brand: Festo

Electric pressure regulator PREL-90-HP3-V1-A-40CFX-S1-5

The Festo 1709137 is an electrical size 90 structural design component featuring a nominal width DN of 24 and series L designation, engineered for vertical mounting positions. This electrically adjustable pressure regulator provides constant output pressure with primary pressure compensation and secondary exhausting across an operating pressure range of 0 to 5 MPa (0 to 50 bar) and a pressure regulation range of 2 bar to 40 bar. It operates on a nominal DC voltage of 24 V, supporting a 4 - 20 mA analog output signal range, a 0 - 10 V analog input signal range, and 0 - 10 V setpoint/actual values. Rated with a CRC of 2 for moderate corrosion stress and VDMA24364 Zone III LABS conformity, the unit processes compressed air as per ISO 8573-1:2010 [7:4:4] or inert gases within a medium temperature of 5 °C to 50 °C and storage temperature of -10 °C to 60 °C, backed by Special Equipment Type Test Certification and food industry applicability detailed in supplementary materials. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 1709137
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 1709137.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Size: 90
Nominal width DN: 24
Series: L
Mounting position: Vertical
Actuation type: Electrical
Structural design: Electrically adjustable pressure regulator
Controller function: Constant output pressure | With primary pressure compensation | With secondary exhausting
Operating pressure: 0 MPa...5 MPa | 0 bar...50 bar
Pressure regulation range: 2 bar...40 bar
Nominal operating voltage DC: 24 V
Analog output signal range: 4 - 20 mA
Analog input signal range: 0 - 10 V
Setpoint/actual values: Voltage type 0 - 10 V
Certication: Special Equipment Type Test Certication
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4] | Inert gases
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364 Zone III
Storage temperature: -10 °C...60 °C
For use in the food industry: See supplementary material information
Temperature of medium: 5 °C...50 °C
Ambient temperature: 5 °C...50 °C
Product weight: 6100 g
Electrical connection IN: Plug, M12, 5-pin, A-coded
Electrical connection OUT: Plug, M12, 5-pin, A-coded
Type of mounting: Alternatively: | On service unit | With accessories
Pneumatic connection 1: G1
Pneumatic connection 11: G1/4

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 1709137. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
