Name: Festo 1709213 Electric pressure regulator PREL-186-HP3-A4-A-40CFX-1
Brand: Festo

Electric pressure regulator PREL-186-HP3-A4-A-40CFX-1

The Festo 1709213 is an electrical industrial component of series L with size 186 and a nominal width DN of 45, featuring a structural design as an electrically adjustable pressure regulator with constant output pressure, primary pressure compensation, and secondary exhausting. It operates within an operating pressure range of 0 MPa to 5 MPa (0 bar to 50 bar) and a pressure regulation range of 0.4 bar to 40 bar, utilizing a nominal operating voltage of 24 V DC along with 4-20 mA analog input and output signal ranges for current type setpoint and actual values. Certified with a Special Equipment Type Test Certification and carrying CE and UKCA markings as per pressure equipment directives, this vertical-mounting regulator accommodates compressed air per ISO 8573-1:2010 [7:4:4] or inert gases, and exhibits a corrosion resistance class (CRC) of 2 with VDMA24364 Zone III LABS conformity. Submit the exact part number, quantity, and application requirements for a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 1709213
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 1709213.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Size: 186
Nominal width DN: 45
Series: L
Mounting position: Vertical
Actuation type: Electrical
Structural design: Electrically adjustable pressure regulator
Controller function: Constant output pressure | With primary pressure compensation | With secondary exhausting
Operating pressure: 0 MPa...5 MPa | 0 bar...50 bar
Pressure regulation range: 0.4 bar...40 bar
Max. pressure hysteresis: 0.806 bar
Nominal operating voltage DC: 24 V
Analog output signal range: 4 - 20 mA
Analog input signal range: 4 - 20 mA
Setpoint/actual values: Current type 4–20 mA
Certication: Special Equipment Type Test Certication
CE marking (see declaration of conformity): as per EU pressure equipment directive
UKCA marking (see declaration of conformity): according to UK regulations for pressure equipment
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4] | Inert gases
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364 Zone III
Storage temperature: -10 °C...60 °C
For use in the food industry: See supplementary material information
Temperature of medium: 5 °C...50 °C
Ambient temperature: 5 °C...50 °C
Electrical connection IN: Plug, M12, 5-pin, A-coded
Electrical connection OUT: Plug, M12, 5-pin, A-coded
Type of mounting: Alternatively: | On service unit | With accessories
