Reference imageConfirm configuration by manufacturer part number.
Festo
171063
Vacuum generator VADMI-300-LS-P
The Festo 171063 is an industrial component featuring a 3 mm nominal width Laval nozzle, a 22 mm width dimension, a closed muffler construction type, and any mounting position with high vacuum ejector characteristics. This part incorporates an integrated ejector pulse valve, flow control valve, electric on-off valve, filter, electric air-saving function, check valve, and vacuum switch, utilizing a piezoresistive measuring principle for relative pressure with a 40 µm grade of filtration and non-detenting manual override. It includes an LED display, optical switching status indication, potentiometer setting options, threshold value comparator switching function with N.O. contact, reverse polarity protection for all electrical connections, a -60 kPa to -10 kPa setting range hysteresis, and a -90 kPa to -20 kPa setting range threshold value. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 171063
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 171063.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width of Laval nozzle
- 3 mm
- Width dimension
- 22 mm
- Muffler construction type
- Closed
- Mounting position
- Any
- Ejector characteristics
- High vacuum
- Grade of ltration
- 40 µm
- Manual override
- Non-detenting
- Integrated function
- Ejector pulse valve, electric | Flow control valve | Electric on-off valve | Filter | Electric air-saving function | Check valve | Vacuum switch
- Measured variable
- Relative pressure
- Measuring principle
- Piezoresistive
- Switching element function
- N.O. contact
- Switching function
- Threshold value comparator
- Valve function
- Closed
- Reverse polarity protection
- for all electrical connections
- Display type
- LED
- Setting range hysteresis
- -60 kPa...-10 kPa | -0.6 bar...-0.1 bar
- Hysteresis setting range
- -8.7 psi...-1.45 psi
- Setting options
- Potentiometer
- Switching status indication
- Optical
- Setting range threshold value
- -90 kPa...-20 kPa | -0.9 bar...-0.2 bar
- Threshold value setting range
- -13.05 psi...-2.9 psi
- Operating pressure
- 0.2 MPa...0.8 MPa | 2 bar...8 bar | 29 psi...116 psi
- Max. vacuum
- 85 %
- Nominal operating pressure
- 0.6 MPa
