173885

Name: Festo 173885 Service unit FRC-1-D-MAXI-A-NPT
Brand: Festo

Service unit FRC-1-D-MAXI-A-NPT

The Festo part number 173885 is a Maxi-size industrial component featuring a die-cast zinc housing, 1 NPT pneumatic connections on both sides, and a vertical mounting position with optional in-line installation or retaining bracket mounting. It operates within a pressure range of 0.2 MPa to 1.2 MPa (2 bar to 12 bar), provides a pressure regulation range of 0.5 bar to 12 bar with a 40 µm filtration grade, and delivers a normal nominal flow rate of 8500 l/min using compressed air or inert gases. Submit the exact part number, quantity, and application requirements to receive a quote for this component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 173885
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 173885.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Size: Maxi
Mounting position: Vertical
Condensate drain: Fully automatic
Grade of ltration: 40 µm
Operating pressure: 0.2 MPa...1.2 MPa | 2 bar...12 bar
Pressure regulation range: 0.5 bar...12 bar
Max. pressure hysteresis: 0.04 MPa | 0.4 bar | 5.8 psi
Normal nominal ow rate (normalized to DIN 1343): 8500 l/min
Operating medium: Compressed air as per ISO 8573-1:2010 [7:9:-] | Inert gases
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Air quality class at the output: Compressed air as per ISO 8573-1:2010 [7:8:-]
Temperature of medium: -10 °C...60 °C
Ambient temperature: -10 °C...60 °C
Product weight: 2520 g
Type of mounting: Alternatively: | In-line installation | With retaining bracket
Pneumatic connection 1: 1 NPT
Pneumatic connection 2: 1 NPT
Housing material: Die-cast zinc
Material of bowl: PC

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 173885. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
