Reference imageConfirm configuration by manufacturer part number.
Festo
177716
Fluid separator CQA-22
The Festo part number 177716 is an industrial component featuring a nominal width of 12 mm and a structural design based on the push-pull principle, equipped for pneumatic connections with a 22 mm outside diameter on both connection 1 and connection 2. Fabricated with a POM housing and releasing ring alongside a high-alloy stainless steel tube retaining claw, this unit supports a temperature-dependent operating pressure range of -0.95 bar to 15 bar and an operating pressure range of -0.95 bar to 7 bar across an ambient temperature of -25 °C to 70 °C. It accommodates compressed air operating media in accordance with ISO 8573-1:2010 [7:-:-] with oil lubrication operation possible, exhibits a moderate corrosion resistance class (CRC) of 2, and weighs 76 g with a pack size of 1. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 177716
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 177716.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 12 mm
- Mounting position
- Any
- Pack size
- 1
- Structural design
- Push-pull principle
- Operating pressure for entire temperature range
- -0.95 bar...7 bar
- Temperature-dependent operating pressure
- -0.95 bar...15 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- For use in the food industry
- See supplementary material information
- Temperature of medium
- -25 °C...75 °C
- Ambient temperature
- -25 °C...70 °C
- Product weight
- 76 g
- Pneumatic connection 1
- For piping system/pneumatic tubing outside diameter of 22 mm
- Pneumatic connection 2
- for piping system/pneumatic tubing outside diameter of 22 mm
- Note on materials
- RoHS compliant
- Housing material
- POM
- Releasing ring material
- POM
- Material of tube retaining claw
- high-alloy stainless steel
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 177716. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
