Reference imageConfirm configuration by manufacturer part number.
Festo
183738
Push-in fitting QSM-M7-1/8-I-U-M
The Festo part number 183738 is a mini straight industrial component featuring an M7 external thread on pneumatic connection 1 and a 1/8-inch outside diameter tubing fit on pneumatic connection 2, operating via a push-pull structural design with a sealing ring on the screwed plug. It functions with compressed air conforming to ISO 8573-1:2010 [7:-:-], accommodating lubricated operation across an operating pressure range of -0.095 MPa to 1 MPa (-0.95 bar to 10 bar, or -13.775 psi to 145 psi) and an ambient temperature range of 0 °C to 60 °C. The unit incorporates an internal hexagon AF 2 mounting type with a nominal tightening torque of 2.47 ft-lbf (tolerance ±20%), a corrosion resistance class of 1, VDMA24364-B1/B2-L LABS conformity, a product weight of 0.219 oz, and any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 183738
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 183738.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- Mini
- Nominal width
- 0.079 in
- Type of seal on screwed plug
- Sealing ring
- Mounting position
- Any
- Design
- Straight design
- Pack size
- 1
- Structural design
- Push-pull principle
- Operating pressure for entire temperature range
- -0.095 MPa...1 MPa | -0.95 bar...10 bar | -13.775 psi...145 psi
- Maritime classication
- See certicate
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Lubricated operation possible
- Corrosion resistance class (CRC)
- 1 - Low corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- 0 °C...60 °C
- Nominal tightening torque
- 2.47 ft-lbf
- Tolerance for nominal tightening torque
- ±20%
- Product weight
- 0.219 oz
- Type of mounting
- Internal hexagon, AF 2
- Pneumatic connection 1
- External thread M7
- Pneumatic connection 2
- for pneumatic tubing outside diameter 1/8"
- Ambient temperature Fahrenheit
- 32 °F...140 °F
- Releasing ring color
- Gray
- Note on materials
- RoHS compliant
- Housing material
- Brass | Nickel-plated
- Releasing ring material
- POM
- Material of tubing seal
- NBR
- Material of tube retaining claw
- high-alloy stainless steel
