Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
191196
Shock absorber YSRW-12-20
The Festo 191196 is a size 12 industrial component featuring a 20 mm stroke, single-acting pushing mode of operation, and self-adjusting cushioning with a soft characteristic curve. It accommodates any mounting position within an ambient temperature range of -10 °C to 80 °C, delivering a maximum stop force of 1000 N, 12 J of maximum energy absorption per stroke, and an impact velocity up to 3 m/s at a product weight of 78 g. This unit provides a corrosion resistance class of 2 for moderate stress, VDMA24364-B2-L LABS conformity, and resets in 0.3 s at room temperature or 1 s at minimum ambient temperature. Submit the exact part number, quantity, and application requirements to request a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 191196
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 191196.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- 12
- Stroke
- 20 mm
- Cushioning
- Self-adjusting | Soft characteristic curve
- Mounting position
- Any
- Position sensing
- None
- Max. impact velocity
- 3 m/s
- Reset time at room temperature
- 0.3 s
- Reset time at min. ambient temperature
- 1 s
- Mode of operation
- Pushing | Single-acting
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Ambient temperature
- -10 °C...80 °C
- Cushioning length
- 20 mm
- Max. stop force
- 1000 N
- Max. energy absorption per stroke
- 12 J
- Max. energy absorption per hour
- 41000 J
- Max. residual energy
- 0.05 J
- Resetting force
- 5 N
- Min. insertion force
- 35 N
- Product weight
- 78 g
- Load range
- 30 kg
- Type of mounting
- With locknut
- Note on materials
- RoHS compliant
- Seals material
- NBR
- Housing material
- Steel, galvanized
- Piston rod material
- High-alloy steel
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 191196. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
