192375

Name: Festo 192375 Filter regulator LFR-3/4-D-O-DI-MAXI
Brand: Festo

Filter regulator LFR-3/4-D-O-DI-MAXI

The Festo part number 192375 is a D-series Maxi structural filter regulator featuring a manual rotating condensate drain, a 40 µm grade of filtration, and a metal bowl guard with a maximum condensate volume of 43 cm³. It operates within a pressure range of 1 bar to 16 bar and regulates pressure from 0.5 bar to 12 bar, delivering a normal nominal flow rate of 6800 l/min for compressed air as per ISO 8573-1:2010 [-:9:-] or inert gases. Configured with a rotary knob with detent for actuator locking, a G1/4 pressure gauge setup, and a vertical ±5° mounting position, this unit maintains a maximum pressure hysteresis of 0.4 bar under moderate corrosion stress. Submit the exact part number, quantity, and application requirements for an RFQ quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 192375
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 192375.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Size: Maxi
Series: D
Actuator lock: Rotary knob with detent
Mounting position: Vertical ±5°
Grade of ltration: 40 µm
Condensate drain: Manual, rotating
Structural design: Filter regulator without pressure gauge
Max. condensate volume: 43 cm³
Bowl guard: Metal bowl guard
Pressure gauge: Set up for G1/4
Operating pressure: 0.1 MPa...1.6 MPa | 1 bar...16 bar
Pressure regulation range: 0.5 bar...12 bar
Max. pressure hysteresis: 0.04 MPa | 0.4 bar | 5.8 psi
Normal nominal ow rate (normalized to DIN 1343): 6800 l/min
Operating medium: Compressed air as per ISO 8573-1:2010 [-:9:-] | Inert gases
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Storage temperature: -10 °C...60 °C
Air quality class at the output: Compressed air as per ISO 8573-1:2010 [7:8:4] | Inert gases
Temperature of medium: -10 °C...60 °C
Ambient temperature: -10 °C...60 °C
Product weight: 1600 g
Type of mounting: In-line installation
Pneumatic connection 1: G3/4
Pneumatic connection 2: G3/4
Note on materials: RoHS compliant
Housing material: Die-cast zinc

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 192375. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
