Festo
1941568
Clamping unit DADL-EL-Q11-63
The Festo 1941568 is a size 63 industrial component utilizing a piston and piston rod structural design with an adjustment range of swivel angle from 55 to 200 degrees. Constructed with a hard-anodized aluminum housing, anodized aluminum housing cover and disc, polymer bearing, NBR and TPE-U seals, and galvanized steel screws, this unit operates at pressures between 0.3 MPa and 0.8 MPa (3 bar to 8 bar, 43.5 psi to 116 psi) using ISO 8573-1:2010 [7:-:-] compressed air. It features a product weight of 2380 g, G1/8 pneumatic connections, through-hole and centering sleeve mounting, position sensing via proximity switch, and a moderate corrosion resistance class (CRC) of 2. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 1941568
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 1941568.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- 63
- Adjustment range of swivel angle
- 55 deg...200 deg
- Structural design
- Piston | Piston rod
- Position sensing
- Via proximity switch
- Operating pressure
- 0.3 MPa...0.8 MPa | 3 bar...8 bar | 43.5 psi...116 psi
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 °C...60 °C
- Product weight
- 2380 g
- Type of mounting
- Via through-hole and centering sleeve
- Pneumatic connection
- G1/8
- Note on materials
- RoHS compliant
- Seals material
- NBR | TPE-U(PU)
- Housing material
- Aluminum | Hard-anodized
- Housing cover material
- Aluminum | Anodized
- Material of bearing
- Polymer
- Disc material
- Aluminum | Anodized
- Material of screws
- Steel | Galvanized
- Mode of operation
- Single-acting | Pulling
