Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
196984
Fluid separator CQA-28
The Festo 196984 industrial component features a 20 mm nominal width and a brass housing built with the push-pull structural design for vertical mounting positions. Operating on compressed air compliant with ISO 8573-1:2010 [7:-:-], this part handles a temperature-dependent operating pressure of -0.95 bar to 10 bar and an entire temperature range pressure of -0.95 bar to 7 bar with a medium temperature of -25 °C to 75 °C. It is equipped with push-in sleeve CQ-28 pneumatic connections on both ends, weighs 18 g, and meets VDMA24364 Zone III LABS conformity with a CRC rating of 2. Submit part number 196984, desired quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 196984
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 196984.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 20 mm
- Mounting position
- Vertical
- Pack size
- 1
- Structural design
- Push-pull principle
- Operating pressure for entire temperature range
- -0.95 bar...7 bar
- Temperature-dependent operating pressure
- -0.95 bar...10 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- Temperature of medium
- -25 °C...75 °C
- Ambient temperature
- -25 °C...70 °C
- Product weight
- 18 g
- Pneumatic connection 1
- Push-in sleeve CQ-28
- Pneumatic connection 2
- Push-in sleeve CQ-28
- Note on materials
- RoHS compliant
- Housing material
- Brass
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 196984. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
