Name: Festo 197019 Air solenoid valve MHA1-M5H-3/2O-0,6-HC
Brand: Festo

Air solenoid valve MHA1-M5H-3/2O-0,6-HC

The Festo part number 197019 is a 3/2-way monostable open industrial component featuring a 10 mm width, a nominal width of 0.7 mm, and a normal nominal flow rate of 10 l/min. This directly controlled poppet valve operates on 12V DC with an operating pressure range of 0 MPa to 0.6 MPa (0 bar to 6 bar, 0 psi to 87 psi) and utilizes a mechanical spring for reset. Built with a soft sealing principle, an adjustable exhaust air function, and a non-detenting manual override, it includes sub-base pneumatic working ports, IP40 protection, and c UL us recognition (OL) via UL MH19482. Submit the exact part number, quantity, and application requirements for an RFQ quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 197019
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 197019.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Valve function: 3/2-way, monostable, open
Actuation type: Electrical
Width: 10 mm
Normal nominal ow rate (normalized to DIN 1343): 10 l/min
Pneumatic working port: Sub-base
Operating voltage: 12V DC
Operating pressure: 0 MPa...0.6 MPa | 0 bar...6 bar | 0 psi...87 psi
Structural design: Poppet valve with spring return
Reset method: Mechanical spring
Degree of protection: IP40
Certication: c UL us - recognized (OL)
Certicate issuing authority: UL MH19482
Nominal width: 0.7 mm
Width dimension: 10 mm
Exhaust air function: Adjustable
Sealing principle: Soft
Mounting position: Any
Manual override: Non-detenting
Type of control: directly
Flow direction: Non-reversible
Valve position ID: Label
Lap: Negative overlap
Note on forced dynamization: Switching frequency at least once a week
Max. switching frequency: 20 Hz
Switching time oﬀ: 4 ms
On switching time: 4 ms
Duty cycle: 100%
Electrical power consumption: 1 W
Coil characteristics: 12 V DC: 1.0 W
Permissible voltage uctuations: +/- 10%

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 197019. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
