2078

Name: Festo 2078 Distributor block FR-8-1/4
Brand: Festo

Distributor block FR-8-1/4

The Festo part number 2078 is an industrial component featuring a die-cast aluminum housing with 8 outlets and 1 supply line utilizing a G1/2 internal thread for pneumatic connection 1 and G1/4 internal threads for pneumatic connection 2. This assembly provides an 11.5 mm nominal width, an operating pressure range of 0 bar to 16 bar across an ambient temperature range of -10 °C to 60 °C, and a product weight of 230 g. It accommodates compressed air operating media as per ISO 8573-1:2010 [7:-:-] with possible oil lubrication, features a nominal tightening torque of 14 Nm with a ±20% tolerance, and maintains a 0 - No corrosion stress resistance class with RoHS compliance and VDMA24364-B1/B2-L LABS conformity for any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 2078
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 2078.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Nominal width: 11.5 mm
Mounting position: Any
Operating pressure for entire temperature range: 0 bar...16 bar
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 0 - No corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Ambient temperature: -10 °C...60 °C
Nominal tightening torque: 14 Nm
Tolerance for nominal tightening torque: ±20%
Product weight: 230 g
No. of outlets: 8
No. of supply lines: 1
Pneumatic connection 1: Internal thread G1/2
Pneumatic connection 2: Internal thread G1/4
Note on materials: RoHS compliant
Housing material: Die-cast aluminum

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 2078. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
