Festo
2111
One-way flow control valve GRR-1/2
The Festo 2111 is an industrial component featuring a one-way flow control function with G1/2 pneumatic connections on both ports and a roller lever adjusting element. Built with a wrought aluminum alloy housing weighing 735 g, this part mounts via through-hole in any position and operates within a pressure range of 0.3 bar to 10 bar. It delivers a standard nominal flow rate of 1300 l/min in the flow control direction and 1250 l/min in the non-return direction using compressed air conforming to ISO 8573-1:2010 [7:-:-] at ambient and medium temperatures from -10 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 2111
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 2111.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- One-way ow control function
- Pneumatic connection 1
- G1/2
- Pneumatic connection 2
- G1/2
- Adjusting element
- Roller lever
- Type of mounting
- With through-hole
- Standard nominal ow rate in ow control direction
- 1300 l/min
- Standard nominal ow rate in non-return direction
- 1250 l/min
- Operating pressure
- 0.3 bar...10 bar
- Ambient temperature
- -10 °C...60 °C
- Housing material
- Wrought aluminum alloy
- Mounting position
- Any
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Temperature of medium
- -10 °C...60 °C
- Product weight
- 735 g
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 2111. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
