Festo
34413
Solenoid coil MSFG-42-OD
The Festo 34413 is an industrial component featuring a 42 V DC, 5.5 W coil with 100% duty cycle and a minimum pick-up time of 10 ms. Constructed from duroplast, copper, and steel with copper winding, this IP65-rated part supports any mounting position via a knurled nut and includes a 3-pin electrical connection with plug tags for MSSD-F. It operates within an ambient temperature range of -5 °C to 40 °C, accommodates +/- 10% permissible voltage fluctuations, features a maximum socket tightening torque of 0.4 Nm, and complies with VDMA24364-C1-L LABS conformity and RoHS material directives at a product weight of 55 g. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 34413
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 34413.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Mounting position
- Any
- Switching position indication
- No
- Min. pick-up time
- 10 ms
- Duty cycle
- 100%
- Coil characteristics
- 42 V DC: 5.5 W
- Permissible voltage uctuations
- +/- 10%
- LABS (PWIS) conformity
- VDMA24364-C1-L
- Degree of protection
- IP65
- Ambient temperature
- -5 °C...40 °C
- Max. tightening torque of socket
- 0.4 Nm
- Product weight
- 55 g
- Electrical connection
- 3-pin | Plug ags with connection diagram as per Festo standard for MSSD-F
- Type of mounting
- With knurled nut
- Note on materials
- RoHS compliant
- Solenoid coil material
- Duroplast | Copper | Steel
- Material of winding
- Copper
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 34413. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
