Festo
35310
Exhaust air flow control valve GRE-3/8
The Festo part number 35310 is an industrial component featuring a sound pressure flow control function with an integrated muffler and a G3/8 pneumatic connection. Constructed with a wrought aluminum alloy screwed plug, brass adjusting screw, and NBR seals, this screw-in valve operates within a pressure range of 0 bar to 10 bar and an ambient temperature span of -10 °C to 70 °C. It delivers a standard nominal flow rate of 2000 l/min in the flow control direction, supports compressed air operating media according to ISO 8573-1:2010 [7:4:4], and weighs 50 g. Submit the exact part number, quantity, and application requirements to receive a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 35310
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 35310.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- Sound pressure ow control function
- Selection of additional function
- with muffler
- Pneumatic connection 1
- G3/8
- Adjusting element
- Slotted screw
- Type of mounting
- Screw-in
- Standard nominal ow rate in ow control direction
- 2000 l/min
- Standard ow rate 6->0 bar
- 3 l/min...2000 l/min
- Operating pressure
- 0 bar...10 bar
- Ambient temperature
- -10 °C...70 °C
- Mounting position
- Any
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Temperature of medium
- -10 °C...70 °C
- Max. tightening torque
- 15 Nm
- Product weight
- 50 g
- Material of screwed plug
- Wrought aluminum alloy
- Note on materials
- RoHS compliant
- Seals material
- NBR
- Material of adjusting screw
- Brass
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 35310. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
