3608

Name: Festo 3608 Barb tubing fitting N-3/8-P-6
Brand: Festo

Barb tubing fitting N-3/8-P-6

Engineered with a straight design and an anodized aluminum housing, this Festo industrial component features a G3/8 external thread and a connection for 6 mm I.D. tubing. It operates within a pressure range of -0.95 bar to 16 bar and an ambient temperature range of -10 °C to 60 °C using compressed air as per ISO 8573-1:2010 [7:-:-]. The unit includes a sealing ring, a 4.5 mm nominal width, a maximum tightening torque of 15 Nm, and a product weight of 8.71 g with CRC 2 moderate corrosion resistance. Submit part number 3608, the required quantity, and application requirements to receive a formal quotation.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 3608
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 3608.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Nominal width: 4.5 mm
Type of seal on screwed plug: Sealing ring
Mounting position: Any
Design: Straight design
Pack size: 1
Operating pressure for entire temperature range: -0.95 bar...16 bar
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Ambient temperature: -10 °C...60 °C
Max. tightening torque: 15 Nm
Product weight: 8.71 g
Pneumatic connection 1: External thread G3/8
Pneumatic connection 2: For tubing I.D. 6 mm
Note on materials: RoHS compliant
Housing material: Anodized aluminum

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 3608. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
