Festo
4080491
Digital output module CPX-E-8DO
The Festo industrial component, part number 4080491, measures 18.9 mm in width, 76.6 mm in length, and 124.3 mm in height with a product weight of 93 g. It features DIN rail mounting capability for both vertical and horizontal positions, operating within an ambient temperature range of -5 °C to 50 °C, which extends to 60 °C specifically for vertical installations. The unit is rated to IP20 protection, provides PELV direct and indirect contact protection, and complies with EU EMC and RoHS directives alongside UKCA, KC-EMV, RCM, and c UL us-Listed certifications. Submit the exact part number, quantity, and application requirements for a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4080491
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4080491.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 18.9 mm x 76.6 mm x 124.3 mm
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Product weight
- 93 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- Max. cable length
- 30 m outputs
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Certicate issuing authority
- UL E239998
- Note on materials
- RoHS compliant
- Housing material
- PA
- Diagnostics via LED
- Faults per channel | Faults per module | Status per channel
- Diagnostics via bus
- Module Error | Output short circuit/overload
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 4080491. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
