Festo
4080492
Digital input module CPX-E-16DI
The Festo 4080492 is an industrial component measuring 18.9 mm in width, 76.6 mm in length, and 124.3 mm in height with a product weight of 102 g. It features DIN rail mounting capability, supports vertical and horizontal mounting positions, and operates within an ambient temperature range of -5 °C to 50 °C, extending up to 60 °C for vertical installations. Certified with cUL us - Listed (OL), RCM compliance mark, CE, and UKCA markings, this unit complies with EU and UK EMC and RoHS directives. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4080492
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4080492.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 18.9 mm x 76.6 mm x 124.3 mm
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Product weight
- 102 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Max. cable length
- 30 m inputs
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Certicate issuing authority
- UL E239998
- Note on materials
- RoHS compliant
- Housing material
- PA
- Diagnostics via LED
- Faults per module | Status per channel
- Diagnostics via bus
- Sensor supply short circuit/overload
- Max. address capacity inputs
- 2 byte
- Module parameters
- Sensor supply short circuit diagnostics
