Festo
4080494
Analogue output module CPX-E-4AO-U-I
The Festo 4080494 industrial component features dimensions of 18.9 mm by 76.6 mm by 124.3 mm and weighs 96 g, with mounting designed for DIN rails in either vertical or horizontal positions. It operates within an ambient temperature range of -5 °C to 50 °C, extending up to 60 °C for vertical installations, and provides an IP20 degree of protection alongside PELV direct and indirect contact protection. Certified with c UL us - Listed (OL), RCM compliance, and KC-EMV marks, this unit complies with EU and UK EMC and RoHS directives. Submit the exact part number, quantity, and application requirements to request a quote for this component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4080494
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4080494.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 18.9 mm x 76.6 mm x 124.3 mm
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Product weight
- 96 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- Max. cable length
- 30 m outputs | Shielded
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Note on materials
- RoHS compliant
- Housing material
- PA
- Material of screws
- Galvanized steel
- Diagnostics via LED
- Faults per channel | Faults per module
- Diagnostics via bus
- Actuator supply short circuit/overload | Analog output short circuit/overload
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 4080494. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
