Festo
4080497
Bus module CPX-E-PN
The Festo 4080497 is an industrial component designed for DIN rail mounting, measuring 42.2 mm in width, 76.5 mm in length, and 125.8 mm in height with a 18.9 mm width dimension. Weighing 145 g, this unit supports up to 10 modules and operates within an ambient temperature range of -5 °C to 50 °C, extending up to 60 °C for vertical installations. It features an IP20 degree of protection, PELV protection against direct and indirect contact, and conforms to VDMA24364 Zone III LABS conformity with CRC 0 corrosion resistance. Submit your exact part number, quantity, and application requirements to receive a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4080497
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4080497.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 42.2 mm x 76.5 mm x 125.8 mm
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Max. number of modules
- 10
- Product weight
- 145 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Certicate issuing authority
- UL E239998
- Note on materials
- RoHS compliant
- Housing material
- PA
- Diagnostics via LED
- Force mode | Network error | Network status, port 1 | Network status, port 2 | Power supply for electronics/sensors | Load power supply | System fault
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 4080497. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
