Festo
4080498
Bus module CPX-E-EC
The Festo 4080498 is an industrial component measuring 42.2 mm in width, 76.5 mm in length, and 125.8 mm in height, with an 18.9 mm width dimension and a product weight of 145 g. This IP20-rated unit supports vertical or horizontal mounting positions on a DIN rail, accommodates up to 10 modules, and operates within an ambient temperature range of -5 °C to 50 °C, extending to 60 °C for vertical installation. It features PELV protection against direct and indirect contact, carries CE, UKCA, KC, RCM, and c UL us - Listed (OL) certifications, and complies with VDMA24364 Zone III LABS conformity with CRC 0 corrosion resistance. Submit the exact part number, quantity, and application requirements to receive an official quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4080498
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4080498.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 42.2 mm x 76.5 mm x 125.8 mm
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Max. number of modules
- 10
- Product weight
- 145 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Certicate issuing authority
- UL E239998
- Note on materials
- RoHS compliant
- Housing material
- PA
- Diagnostics via LED
- EtherCAT Error | EtherCAT RUN | Force mode | Modify | Module status | Power supply for electronics/sensors
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 4080498. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
