Name: Festo 4131 Pressure gauge OH-22-RT
Brand: Festo

Pressure gauge OH-22-RT

The Festo part number 4131 is a 25 g industrial component featuring G1/8 pneumatic connections and standard panel mounting for a Ø22.5 cutout. Designed for any mounting position, it operates within a pressure range of 1.4 bar to 8 bar using compressed air conforming to ISO 8573-1:2010 [7:-:-] at medium and ambient temperatures between -10 °C and 45 °C. This RoHS-compliant unit complies with VDMA24364-B1/B2-L LABS conformity and permits oil lubrication operation, which is required for further use. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 4131
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 4131.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Mounting position: Any
Operating pressure: 1.4 bar...8 bar
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Temperature of medium: -10 °C...45 °C
Ambient temperature: -10 °C...45 °C
Product weight: 25 g
Type of mounting: Panel mounting Ø22.5
Pneumatic connection: G1/8
Note on materials: RoHS compliant

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 4131. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
