Festo
4197366
Cable fitting NETC-P-M12-EX4
The Festo 4197366 is an M12x1.5 industrial component weighing 4 g with a blue PA cable connector, EPDM seals, and an IP66 and IP68 degree of protection for cable diameters of 4 mm to 7 mm. It features Ex eb IIC Gb gas ignition protection, Ex tb IIIC Db dust ignition protection, IEC-EX EPL Gb and EPL Db certifications, ATEX and RoHS CE markings, and VDMA24364-B2-L LABS conformity. Operating within an ambient temperature range of -20 °C to 70 °C, the RoHS-compliant unit exhibits a corrosion resistance class of CRC 3 for high corrosion stress. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4197366
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4197366.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Ambient temperature
- -20 °C...70 °C
- Degree of protection
- IP66 | IP68
- Type of ignition protection for gas
- Ex eb IIC Gb
- Type of (ignition) protection for dust
- Ex tb IIIC Db
- Explosive ambient temperature
- -20°C <= Ta <= +70°C
- Explosion protection certication outside the EU
- EPL Db (IEC-EX) | EPL Gb (IEC-EX)
- CE marking (see declaration of conformity)
- as per EU explosion protection directive (ATEX) | As per EU RoHS directive
- Size
- M12x1.5
- Cable diameter
- 4 mm...7 mm
- Color
- Blue
- Material for cable connector
- PA
- Seals material
- EPDM
- Product weight
- 4 g
- Pack size
- 1
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Note on materials
- RoHS compliant
- Corrosion resistance class (CRC)
- 3 - High corrosion stress
