Festo
4252741
Controller CPX-E-CEC-C1-PN
This Festo industrial component, part number 4252741, features a width dimension of 18.9 mm, a product weight of 288 g, and DIN rail mounting capability for horizontal or vertical positions. It operates within an ambient temperature range of -5 °C to 50 °C, extending up to 60 °C for vertical installation, and maintains IP20 protection with VDMA24364 Zone III LABS conformity. Diagnostics are provided via extensive LED indicators alongside a DIP switch for RUN/STOP control and PROFINET, LLDP, and ring redundancy fieldbus protocols. Submit the exact part number, quantity, and application requirements for an official quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4252741
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4252741.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Product weight
- 288 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Note on materials
- RoHS compliant
- Diagnostics via LED
- Force mode | Module status | Network error | Network status, engineering port 1 | Engineering port 2 network status | EtherCAT network status | Network status, port 1 | Network status, port 2 | Run | Power supply for electronics/sensors | Load power supply | System fault | Maintenance required
- Control elements
- DIP switch for RUN/STOP | Optional: Operator unit CDSB
- Fieldbus interface, protocol
- LLDP | MRP, MRPD (ring redundancy) | PROFINET I&M0 .. 3
