Festo
4252742
Controller CPX-E-CEC-C1-EP
The Festo part number 4252742 is an industrial component with an 18.9 mm width and a product weight of 288 g, featuring DIN rail mounting for either vertical or horizontal installation positions. It operates within an ambient temperature range of -5 °C to 50 °C, or up to 60 °C for vertical installation, and supports an EtherNet/IP fieldbus interface with ACD and DLR protocols. The unit provides diagnostics via multiple LED indicators and includes control elements such as a DIP switch for RUN/STOP and a rotary switch for address setting. Submit the exact part number, quantity, and application requirements to receive a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4252742
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4252742.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Product weight
- 288 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Note on materials
- RoHS compliant
- Diagnostics via LED
- Force mode | Module status | Network status | Network status, engineering port 1 | Engineering port 2 network status | EtherCAT network status | Network status, port 1 | Network status, port 2 | Run | Power supply for electronics/sensors | Load power supply | System fault
- Control elements
- DIP switch for RUN/STOP | Rotary switch for address setting | Optional: Operator unit CDSB
- Fieldbus interface, protocol
- ACD (Address Conict Detection) | DLR (Device Level Ring) | EtherNet/IP
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 4252742. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
