Festo
4252744
Controller CPX-E-CEC-M1-EP
The Festo part number 4252744 is an industrial component featuring an 18.9 mm width and a weight of 288 g, designed for mounting on a DIN rail in either vertical or horizontal positions. It operates within an ambient temperature range of -5 °C to 50 °C, extending up to 60 °C for vertical installations, and complies with IP20 protection standards alongside PELV direct and indirect contact protection. Equipped with comprehensive LED diagnostics, a DIP switch, and a rotary switch, this unit supports EtherNet/IP fieldbus communication with DLR and ACD protocols. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 4252744
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 4252744.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width dimension
- 18.9 mm
- Type of mounting
- With DIN rail
- Product weight
- 288 g
- Mounting position
- Vertical | Horizontal
- Ambient temperature
- -5 °C...50 °C
- Note on ambient temperature
- -5 - 60 °C for vertical installation
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Note on materials
- RoHS compliant
- Diagnostics via LED
- Force mode | Module status | Network status | Network status, engineering port 1 | Engineering port 2 network status | EtherCAT network status | Network status, port 1 | Network status, port 2 | Run | Power supply for electronics/sensors | Load power supply | System fault
- Control elements
- DIP switch for RUN/STOP | Rotary switch for address setting | Optional: Operator unit CDSB
- Fieldbus interface, protocol
- ACD (Address Conict Detection) | DLR (Device Level Ring) | EtherNet/IP
