Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
5105628
Encoder cable NEBM-T1G8-E-25-N-S1G15
This Festo industrial component, part number 5105628, features a product weight of 1300 g and operates within a DC and AC operating voltage range of 0 V to 30 V with a nominal operating voltage of 24 V. The field device side utilizes a straight square socket connection with ITT M3 technology containing 12 pins and 8 occupied wires, while the control side features a straight square plug connection utilizing Sub-D technology with 15 pins and 8 occupied wires. The cable designation is without a label holder. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 5105628
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 5105628.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Cable designation
- Without label holder
- Product weight
- 1300 g
- Electrical connection 1, function
- Field device side
- Electrical connection 1, design
- Square
- Electrical connection 1, connection type
- Socket
- Electrical connection 1, cable outlet
- Straight
- Electrical connection 1, connection technology
- ITT M3
- Electrical connection 1, number of pins/wires
- 12
- Electrical connection 1, occupied pins/wires
- 8
- Electrical connection 2, function
- Control side
- Electrical connection 2, design
- Square
- Electrical connection 2, connection type
- Plug
- Electrical connection 2, cable outlet
- Straight
- Electrical connection 2, connection technology
- Sub-D
- Electrical connection 2, number of pins/wires
- 15
- Electrical connection 2, occupied pins/wires
- 8
- DC operating voltage range
- 0 V...30 V
- Nominal operating voltage DC
- 24 V
- Operating voltage range AC
- 0 V...30 V
- Nominal operating voltage AC
- 24 V
- Shield
- Yes
- Cable length
- 25 m
- Cable characteristic
- Suitable for energy chains
- Bending radius, exible cable installation
- 48 mm
- Cable diameter
- 5.8 mm
- Cable design
- 1 x 4 x 0.15 mm² + 4 x 0.34 mm²
- Nominal conductor cross section
- 0.15 mm² | 0.34 mm²
- Degree of protection
- IP65
- Note on degree of protection
- IP30 for Sub-D plug | In mounted state
- Ambient temperature
- -40 °C...80 °C
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 5105628. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
