Reference imageConfirm configuration by manufacturer part number.
Festo
526006
Vacuum cup without connector ESV-40-BT
The Festo 526006 is a round protective bellows 1.5-fold industrial component featuring a 40 mm suction cup diameter, a 9 mm height compensator, and a suction cup volume of 9.8 cm³ in a reddish brown color with a 72 +/-5 Shore hardness. This RoHS compliant part operates at pressures from -0.95 bar to 0 bar with a nominal operating pressure of -0.7 bar using atmospheric air based on ISO 8573-1:2010 [7:-:-], delivering a breakaway force and holding force of 59 N alongside a lateral force of 22 N at nominal operating pressure. Weighing 10.5 g and featuring VDMA24364-A1-L LABS conformity, it mounts via vacuum connection in any position and accommodates a minimum workpiece radius of 35 mm across an ambient temperature range of -10 °C to 80 °C. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 526006
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 526006.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Suction cup holder height compensator
- 9 mm
- Min. workpiece radius
- 35 mm
- Suction cup diameter
- 40 mm
- Suction cup volume
- 9.8 cm³
- Mounting position
- Any
- Structural design
- Protective bellows
- Suction cup shape
- round protective bellows 1.5-fold
- Operating pressure
- -0.95 bar...0 bar
- Nominal operating pressure
- -0.7 bar
- Operating medium
- Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- LABS (PWIS) conformity
- VDMA24364-A1-L
- Ambient temperature
- -10 °C...80 °C
- Breakaway force at 70% vacuum
- 59 N
- Holding force at nominal operating pressure
- 59 N
- Lateral force at nominal operating pressure
- 22 N
- Product weight
- 10.5 g
- Type of mounting
- Via vacuum connection
- Color
- Reddish brown
- Shore hardness
- 72 +/-5
- Note on materials
- RoHS compliant
- Suction cup material
- VULKOLLAN
