Festo
529521
Soft-start valve MS4-DE-1/4-V230
The Festo 529521 is an electrical 2/2 piston seat industrial component featuring a piloted control type, internal pilot air supply port, and non-reversible flow direction with a normal nominal flow rate of 2000 l/min normalized to DIN 1343. Operating at pressures from 4 bar to 14 bar, this unit utilizes a mechanical spring reset method, offers detenting and non-detenting manual override, supports any mounting position, and runs on a 230 V AC (50/60 Hz) coil with 3.0 VA initial power and 2.4 VA holding power at a 100% duty cycle. Certified as c UL us-recognized (OL) with a CRC rating of 2, it functions with compressed air meeting ISO 8573-1:2010 [7:4:4] or inert gases, permitting oil lubrication that is required for further use. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 529521
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 529521.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Actuation type
- Electrical
- Mounting position
- Any
- Manual override
- Detenting | Non-detenting
- Structural design
- Piston seat
- Reset method
- Mechanical spring
- Type of control
- Piloted
- Pilot air supply port
- Internal
- Flow direction
- Non-reversible
- Valve function
- 2/2
- Switching position indication
- with accessories
- Operating pressure
- 4 bar...14 bar
- b-value
- 0.45
- C value
- 9.6 l/sbar
- Normal nominal ow rate (normalized to DIN 1343)
- 2000 l/min
- Duty cycle
- 100%
- Coil characteristics
- 230 V AC: 50/60 Hz, initial power 3.0 VA, holding power 2.4 VA
- Certication
- c UL us - recognized (OL)
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4] | Inert gases
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- For use in the food industry
- See supplementary material information
- Temperature of medium
- -10 °C...60 °C
- Degree of protection
- IP65
- Ambient temperature
- -10 °C...60 °C
- Product weight
- 263 g
- Electrical connection
- Type C | Plug | As per DIN EN 175301-803 | Rectangular design
- Signal status display
- With accessories
