532025

Name: Festo 532025 Soft-start valve MS6N-DL-3/8
Brand: Festo

Soft-start valve MS6N-DL-3/8

The Festo part number 532025 is a 2/2 directly controlled pneumatic industrial component featuring a piston seat structural design and a mechanical spring reset method. This non-reversible valve operates within a pressure range of 4 bar to 18 bar, delivers a normal nominal flow rate of 5050 l/min, and includes an adjustable exhaust air function with an external pilot air supply port. It functions with compressed air meeting ISO 8573-1:2010 [7:4:4] or inert gases at a medium temperature of -10 °C to 60 °C, exhibits a CRC rating of 2 for moderate corrosion stress, and accommodates oil lubrication. Submit the exact part number, quantity, and application requirements to receive a formal quotation.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 532025
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 532025.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Exhaust air function: Adjustable
Actuation type: Pneumatic
Mounting position: Any
Manual override: None
Structural design: Piston seat
Reset method: Mechanical spring
Type of control: directly
Pilot air supply port: External
Flow direction: Non-reversible
Valve function: 2/2
Operating pressure: 4 bar...18 bar
b-value: 0.48
C value: 21.05 l/sbar
Normal nominal ow rate (normalized to DIN 1343): 5050 l/min
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4] | Inert gases
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B2-L
For use in the food industry: See supplementary material information
Temperature of medium: -10 °C...60 °C
Ambient temperature: -10 °C...60 °C
Product weight: 650 g
Type of mounting: Alternatively: | In-line installation | With accessories
Pneumatic connection 1: 3/8 NPT
Pneumatic connection 2: 3/8 NPT
Note on materials: RoHS compliant
Seals material: NBR
Housing material: Die-cast aluminum

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 532025. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
