Festo
533625
Wait position BWR-HSP-16
The Festo wait position BWR-HSP-16 is an industrial component featuring a maximum wait position module Z-stroke of 25 mm and LABS conformity according to VDMA24364-B2-L. Built with an anodized wrought aluminum alloy housing, the unit integrates an M5 pneumatic connection for the wait position. Request a formal quote by submitting the exact part number, required quantity, and application requirements.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 533625
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 533625.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Maximum wait position module Z-stroke
- 25 mm
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Wait position pneumatic connection
- M5
- Housing material
- Wrought aluminum alloy | Anodized
- Official specification text
- Maximum wait position module Z-stroke 25 mm LABS (PWIS) conformity VDMA24364-B2-L Wait position pneumatic connection M5 Housing material Wrought aluminum alloy Anodized 6/6/26 –
- Document type
- Official Festo EN-US data sheet
- Part number
- 533625
- Product designation
- Wait position BWR-HSP-16
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 533625. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
