Reference imageConfirm configuration by manufacturer part number.
Festo
534303
Ball valve VAPB-3/8-F-40-F03
The Festo 534303 is a mechanical 2-way soft-sealing ball valve featuring a 2/2 valve function, a 10 mm inside diameter, and a DN 10 nominal width with Rp3/8 fitting connections. Designed for in-line installation in any mounting position based on the ISO 5211 norm with an F03 flange hole pattern, it accommodates compressed air as per ISO 8573-1:2010 [-:-:-], inert gas, water, and neutral liquids at medium temperatures ranging from -20 °C to 150 °C. This RoHS compliant component handles a nominal pressure PN of 40 and a reversible flow rate Kv of 9.4 m³/h, requiring a breakaway torque of 3.5 Nm at 10 bar differential pressure and 5 Nm at nominal pressure PN, with switching position indication indicated by slot direction matching flow direction. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 534303
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 534303.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Structural design
- 2-way ball valve
- Actuation type
- Mechanical
- Sealing principle
- Soft
- Mounting position
- Any
- Type of mounting
- In-line installation
- Fitting connection
- Rp3/8
- Switching position indication
- Slot direction = ow direction
- Flange hole pattern
- F03
- Inside diameter
- 10 mm
- Nominal width DN
- 10
- Valve function
- 2/2
- Flow direction
- Reversible
- Nominal pressure of tting PN
- 40
- Breakaway torque at differential pressure, nominal pressure, tting PN
- 5 Nm
- Breakaway torque at 10 bar differential pressure
- 3.5 Nm
- Based on norm
- ISO 5211
- Medium
- Compressed air as per ISO 8573-1:2010 [-:-:-] | Inert gas | Water | Neutral liquids
- Temperature of medium
- -20 °C...150 °C
- Flow rate Kv
- 9.4 m³/h
- Note on materials
- RoHS compliant
- LABS (PWIS) conformity
- VDMA24364 Zone III
- Housing material
- Brass, nickel-plated
- Material number of housing
- 2,0402
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 534303. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
