Reference imageConfirm configuration by manufacturer part number.
Festo
536932
Solenoid coil MSFW-24-50/60-EX
The Festo 536932 is an industrial component weighing 55 g with an IP65 degree of protection and any mounting position. Operating on a 24 V AC 50/60 Hz coil with a power factor cos phi of 0.7, it features an initial power of 9.0 VA, a holding power of 7.0 VA, a minimum pick-up time of 10 ms, and a 100% duty cycle within a permissible ambient temperature range of -5°C to +40°C. Certified for explosive atmospheres in Zone 2 and Zone 22 under ATEX and CN directives, it carries ATEX categories II 3G and II 3D with Ex nA IIC T4 X Gc and Ex tc IIIC T130°C X Dc IP65 protection types, tolerating voltage fluctuations of +/- 10%, frequency fluctuations of +/- 5%, and a maximum socket tightening torque of 0.4 Nm with VDMA24364-B2-L LABS conformity. Submit the exact part number, quantity, and application requirements for a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 536932
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 536932.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Mounting position
- Any
- Min. pick-up time
- 10 ms
- Duty cycle
- 100%
- Power factor cos {phi}
- 0.7
- Coil characteristics
- 24 V AC: 50/60 Hz, initial power 9.0 VA, holding power 7.0 VA
- Permissible frequency uctuations
- +/- 5%
- Permissible voltage uctuations
- +/- 10%
- CE marking (see declaration of conformity)
- as per EU explosion protection directive (ATEX)
- Explosion protection certication outside the EU
- EPL Dc (CN) | EPL Gc (CN)
- Explosion prevention and protection
- Zone 2 (ATEX) | Zone 2 (CN) | Zone 22 (ATEX) | Zone 22 (CN)
- ATEX category gas
- II 3G
- ATEX category for dust
- II 3D
- Type of ignition protection for gas
- Ex nA IIC T4 X Gc
- Type of (ignition) protection for dust
- Ex tc IIIC T130°C X Dc IP65
- Explosive ambient temperature
- -5°C <= Ta <= +40°C
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Degree of protection
- IP65
- Ambient temperature
- -5 °C...40 °C
- Max. tightening torque of socket
- 0.4 Nm
- Product weight
- 55 g
- Electrical connection
- 3-pin | Plug ags with connection diagram as per Festo standard for MSSD-F
- Type of mounting
- With knurled nut
- Note on materials
- RoHS compliant
- Solenoid coil material
- Duroplast | Copper | Steel
- Material of winding
- Copper
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 536932. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
