Festo
538236
Color sensor SOEC-RT-Q50-PS-S-7L
The Festo 538236 is an industrial optoelectronic color sensor utilizing a block design conforming to EN 60947-5-2 standards with RCM and c UL us - Listed certifications. This component operates on a 10 V to 30 V DC voltage range, featuring a white light measurement method with a 4 mm maximum light spot for a 22 mm scanning width within a working range of 12 mm to 32 mm. It includes a PNP light-switching output delivering a maximum output current of 100 mA at a 500 Hz switching frequency, along with pulsed short-circuit protection and RoHS compliance across an ambient temperature range of -10 °C to 55 °C. Submit the exact part number, quantity, and application requirements for a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 538236
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 538236.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Design
- Block design
- Conforms to standard
- EN 60947-5-2
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- Note on materials
- RoHS compliant
- Measured variable
- Position
- Measuring principle
- Optoelectronic
- Method of measurement
- Color sensor
- Type of light
- White
- Max. light spot
- Ø 4 mm for scanning width 22 mm
- Working range
- 12 mm...32 mm
- Ambient temperature
- -10 °C...55 °C
- Switching output
- PNP
- Switching element function
- Light switching
- Max. switching frequency
- 500 Hz
- Max. output current
- 100 mA
- Voltage drop
- 2.4 V
- Short-circuit protection
- Pulsed
- DC operating voltage range
- 10 V...30 V
- Residual ripple
- 10%
- Idle current
- 40 mA
- Reverse polarity protection
- for all electrical connections
- Electrical connection
- 8-pin | M12x1 | Plug
- Size
- 50x50x17 mm
- Type of mounting
- With through-hole
- Product weight
- 38 g
- Housing material
- ABS
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 538236. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
